The NXP 12XS2 eXtreme switch family consists of very low RDSON devices in single or dual high side configuration to replace electromechanical relays or discrete devices in power management applications and DC motor control.
| Product | Datasheet | # of outputs | RDSon (mOhm) | Package | Suggested tool |
| MC33981 | Datasheet [English] | Single | 1 x 4.0 | PQFN 16 | - |
| MC33982 | Datasheet [English] | Single | 1 x 2.0 | PQFN 16 | KIT33982CEVBE |
| MC33984 | Datasheet [English] | Dual | 2 x 4.0 | PQFN 16 | KIT33984CEVBE |
| MC33988 | Datasheet [English] | Dual | 2 x 8.0 | PQFN 16 | KIT33988CEVBE |
Participating products are available for a minimum of 10 years. Designated participating products developed for the automotive, telecom and medical segments are available for a minimum of 15 years.
|
|
|
|
|
|
|
|---|---|---|---|---|---|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
